TCF – Cupellation and Precious Assay

For more information about this product

Cupellation furnaces series TCF are used in the assay process of precious metals alloys. Cupellation is a procedure with the purpose to remove all non noble metal from the alloy to test.
Topcast TCF cupellation furnaces are provided with a built-in electromagnetic induction generator for the heating of the muffle. This leads to ultra fast work cycles and high energy efficiency.

An electronic control regulates the output power, and gives an advanced diagnostic system.

Main advantages of induction heating are:

  1. Fast heating: the muffle is directly heated by induction.
  2. Self-regulating: no more need to regulate power manually, with respect to furnace with silicon carbide resistance rods.
  3. Electrical energy consumption optimization: you don't need to leave the furnace on to prevent thermal shocks to the resistor rods: when work is finished, the furnace may be turned off.
coppelle


TOPCAST may also supply all tools and accessories for cupellation labs.



Technical Specification

  TCF5
Number of Cupels 20 (size 2 = diam.25 mm)
SiC Muffle (LxWxH) 170x222x75 mm
Max Temperature 1200 °C
Supply Threephase - 50/60 Hz
Power 6 kW
Overall dimensions (LxWxH) 500 x 770 x 1580 mm
Weight 250 kg
